JZ115D
HBS
| Quantity: | |
|---|---|
Main Technical Specifications for JZ115D
ü Model: JZ115D
ü Marking Content Numbers, Chinese/English characters, graphics
ü Marking Area 150mm x 100mm
ü Repetition Accuracy 0.05mm
ü Marking Depth 0.02-1mm(Adjustable with different material)
ü Marking Speed 1500-2000mm/Min
ü Power Supply AC220V ±10% 50Hz
ü Power consumption ≦350W
ü JZ115D
ü Circular Marking Φ5-100mm (Large circular clamp can be customized)
ü Non-standard Options
Marking Area 150mmx150mm，200mmx200mm
Circular Marking Can be customized as user’s requirement
ü Packing Details
Dimension(mm): 750X530X390 (marking: 320X440X800, controller:390X380X150)
Net Weight(kg): 64(machine: 58, controller: 6)
Gross Weight(kg): 68
ü Product Features
No need to equip with pneumatic supply or computer, built-in programming system with industrial microcomputer and various USB ports.
Able to mark on wide variety of products or signs made of steel, iron, copper, aluminum, plastic and other material.
Able to mark in Chinese and English characters, Arabic numbers and any picture with harmonized and aesthetic effects.
Serial number automatically increasing or decreasing, VIN code, random code and 2D code, etc.
Key factor is high impact frequency of marking head and fast marking speed making. It’s possible for mass production to customers’ satisfaction.
Very small force of marking pin has no influence on the mechanical property of work pieces.
Marking depth from 0.02~1mm (adjustable), meeting demands for various marking depth.
Simple operation, easy maintenance.
